ZKBio550 – Advanced Biometric Time Attendance & Access Control Terminal

1. Overview

🟢 High-Performance Biometric Time Attendance & Access Control
🟢 Powered by 4th Gen Intel® Core™ i5 Processor
🟢 15” TFT LCD with Projected Capacitive Touch Screen
🟢 Supports Windows and Linux Operating Systems
🟢 Ideal for enterprises needing robust biometric solutions for time attendance & access control

2. System Specifications

🟢 Processor:

• Intel® Core™ i5 (Low Voltage) 4th Gen Processor (2.0 GHz)

🟢 Memory:

• Flash Memory: 2GB DDR3L 1600MHz (Max. 8GB)
• Storage Device: 32GB M-SATA SSD (Max. 512GB)

🟢 Operating System Support:

• Windows 7, 8, 10, and Linux

🟢 Audio:

• Realtek ALC662

3. Display & Touch Features

🟢 Display Type: 15” TFT LCD with LED Backlight
🟢 Resolution: 1024×768
🟢 Touchscreen Type: Projected Capacitive
🟢 Customer Display: LED 8C Digital Tube

4. External I/O Ports

🟢 VGA: 1 × DB-15
🟢 USB Ports: 2 × USB 2.0, 4 × USB 3.0
🟢 Serial Ports: 2 × RS232
🟢 LAN: 1 × RJ45
🟢 Audio: 1 × Line-out, 1 × Mic In

5. Power Specifications

🟢 Power Supply:

• Adaptor: 12V DC 5A

6. Physical & Environmental Conditions

🟢 Operating Temperature: 0°C ~ 35°C (20% - 80% Humidity)
🟢 Storage Temperature: -20°C ~ 55°C (20% - 80% Humidity)
🟢 Dimensions: 490 × 300 × 420 mm
🟢 Net Weight: 5.9 kg
🟢 Color: Black
🟢 Material: ABS
🟢 Certifications: CE, FCC

7. Options & Peripherals

🟢 Second Display: 15” TFT LCD
🟢 Customer Display (VFD): VFD (2 × 20 lines)
🟢 Magnetic Stripe Reader (MSR): 3 Tracks

Why Choose ZKBio550?

✅ High-performance 4th Gen Intel® Core™ i5 processor for fast processing speeds
✅ Enhanced user interaction with 15” TFT LCD touch screen
✅ Supports multiple operating systems for seamless integration
✅ Robust I/O ports for greater connectivity
✅ CE and FCC certified for international quality standards

📞 Contact us today for more details or to explore how ZKBio550 can enhance your biometric access control system!
