ZKBio830 – Advanced Biometric POS Terminal

1. Overview

🟢 High-Performance Biometric POS Terminal
🟢 Powered by Intel® Core™ i3 Processor
🟢 Supports multiple OS including Windows 7, 8, 10 IoT, and Linux
🟢 Ideal for large-scale POS and biometric authentication systems
🟢 15” TFT LCD with optional Projected Capacitive Touch Screen

2. System Specifications

🟢 Processor:

• Intel® Core™ i3-4005U Processor (1.7GHz)

• Intel® Core™ i3-4010U Processor (1.7GHz)

🟢 System Memory:

• 2GB DDR3L 1666MHz (Max. 8GB)

🟢 Storage Device:

• 32GB Msata SSD (Max. 1 × 2.5” HDD / 2.5” SSD)

🟢 Operating System Support:

• Windows 7, 8, 10 IoT Enterprise, POS Ready 7, Linux

🟢 Audio:

• Realtek ALC662

3. Display & Touch Features

🟢 Display Type: 15” TFT LCD, LED Backlight
🟢 Resolution: 1024×768
🟢 Touchscreen Type: Projected Capacitive
🟢 Customer Display: LED (8C Digital Tube)

4. External I/O Ports

🟢 VGA: 1 × DB-15
🟢 USB Ports: 2 × USB 2.0, 4 × USB 3.0
🟢 Serial Ports (COM): 3
🟢 LAN: 1 × RJ45
🟢 Audio: 1 × Line-out
🟢 Cash Drawer: 1
🟢 HDMI: 1

5. Power Specifications

🟢 Power Supply:

• Adaptor: 12V DC 5A

6. Physical & Environmental Conditions

🟢 Operating Temperature: 0℃ ~ 35℃ (20% - 80% Humidity)
🟢 Storage Temperature: -20℃ ~ 55℃ (20% - 80% Humidity)
🟢 Dimensions (W × H × D): 347 × 372 × 402 mm
🟢 Net Weight: 6.10 kg
🟢 Packing Dimensions: 450 × 420 × 480 mm
🟢 Packing Weight: 8.21 kg
🟢 Color: Black
🟢 Certification: CE, FCC

7. Options & Peripherals

🟢 Second Display: 10” TFT LCD
🟢 Customer Display (VFD): VFD (2 × 20 lines)
🟢 Magnetic Stripe Reader (MSR): 3 Tracks
🟢 Fingerprint Reader: Built-in Fingerprint Reader

Why Choose ZKBio830?

✅ High-speed Intel® Core™ i3 processor for enhanced performance
✅ Customizable 15” display with Projected Capacitive Touch option
✅ Versatile operating system support for seamless integration
✅ Certified with CE & FCC for international quality standards

📞 Contact us today for more details or to explore how ZKBio830 can enhance your biometric POS system!
